Short Wave Infrared heaters

Enquire Now
Download Brochure

Introduction

Kerone provides advanced short wave infrared heaters engineered to deliver precision, reliability, and high operational efficiency. With 50+ years of multidisciplinary engineering expertise, Kerone designs fully customized systems tailored to industrial heating, drying, thermal processing, and laboratory standards.

Short wave infrared for the range from 780 nm to 1400 nm, these emitters radiates high heating power. Short wave infrared heaters find its application in the process that requires quick response as short wave IR heaters achieves full temperature with in second.

Why Choose Kerone Short Wave Infrared heaters

Shortwave IR heaters from KERONE are appropriate for all applications in which the attainment of high temperatures in the shortest possible. Radiation eliminates the heat loss arising out of convection and saves energy being used in heating. The heat is delivered directly to the material as the infrared waves penetrate the material to be heated.

Types and Features of Short Wave Infrared heaters

  • High Radiation Density: Delivers intense heat output with minimal space requirements.
  • Short Heating and Cooling Cycles: Rapid response reduces process time.
  • Deep Radiation Penetration: Ensures effective heating within the material.
  • Flexible Heated Lengths: Available from 1 inch up to 120 inches.
  • Infinitely Adjustable Fast-Reaction Control: Precise and responsive power regulation.
  • Stock, Custom, and OEM Sizes: Configurations available to meet specific application needs.
  • High Linear Power Output: Up to 400 watts per inch.
  • Twin Tube Heater Design: Tube format of 23 × 11 mm.
  • High Filament Temperature: Operating temperature range of 1800–2200 °C.

Key Features

  • Ultra-fast heat-up from cold to full operating power in under 1-2 seconds
  • High power density delivering intense radiant energy up to 150 kW/m²
  • Energy efficiency up to 90%, significantly reducing power consumption compared to conventional heaters
  • Precise temperature control with rapid response to setpoint changes
  • Available with gold reflectors for optimized directional heating efficiency
  • Long service life of tungsten halogen elements exceeding 5000 operating hours
  • Compact and modular design enabling flexible system configurations
  • Instant on/off capability ideal for intermittent and cycle-intensive production processes

Powered by AI, ML & IoT

Future-Ready Engineering Driven by AI & IoT

Our advanced AI, ML, and IoT technologies, this solution delivers smarter automation, real-time insights, and predictive intelligence to enhance efficiency and drive future-ready growth.

Real-Time Monitoring & Control

Continuous tracking of process parameters with instant adjustments.

Predictive Maintenance

Intelligent fault detection to prevent failures before they occur.

Adaptive Process Optimization

Dynamic tuning of operations for maximum output and efficiency.

Cloud Dashboards & Analytics

Unified access to real-time insights and performance trends.

Energy & Resource Savings

Smarter utilization of energy to cut costs and reduce waste.

Secure IoT Connectivity

Encrypted data flow with seamless integration across plant systems.

Applications of Short Wave Infrared heaters

Kerone’s Short Wave Infrared Heaters are extensively used in high-speed industrial heating applications. Typical applications include:
  • Pre-heating of metal components prior to forming, bending, or coating operations
  • Curing of paints, varnishes, and powder coatings on automotive and metal components
  • Drying of printed substrates, inks, and coatings in high-speed printing and packaging lines
  • Thermoforming of thermoplastic sheets and films for packaging and product manufacturing
  • Laminating and bonding of composite materials in aerospace and automotive sectors
  • Food processing for surface browning, roasting, and dehydration of products
Kerone’s Short Wave Infrared Heaters deliver unmatched heating speed, precision, and energy efficiency for demanding industrial applications. Their instant response, high power density, and long service life make them a cost-effective choice for manufacturers seeking to improve process throughput, reduce energy consumption, and achieve consistent product quality. Backed by Kerone’s engineering expertise and comprehensive customer support, these heaters provide a reliable and advanced thermal processing solution for a wide range of industries.

Seamless Export Connections Global & Local

Our Global Footprint in Industrial Excellence

Delivering world-class industrial and process solutions across countries with precision, innovation, and reliability.

PeruPeru
ChileChile
ArgentinaArgentina
MexicoMexico
ColombiaColombia
BrazilBrazil
USAUSA
CanadaCanada
United KingdomUnited Kingdom
FranceFrance
GermanyGermany
SpainSpain
ItalyItaly
NetherlandsNetherlands
SwedenSweden
SwitzerlandSwitzerland
PolandPoland
PortugalPortugal
IrelandIreland
CzechiaCzechia
RomaniaRomania
HungaryHungary
AustriaAustria
GreeceGreece
KazakhstanKazakhstan
UzbekistanUzbekistan
TurkmenistanTurkmenistan
AlgeriaAlgeria
EgyptEgypt
NigeriaNigeria
KenyaKenya
South AfricaSouth Africa
Saudi ArabiaSaudi Arabia
UAEUAE
IsraelIsrael
RussiaRussia
IndiaIndia
ChinaChina
JapanJapan
South KoreaSouth Korea
ThailandThailand
VietnamVietnam
MalaysiaMalaysia
SingaporeSingapore
IndonesiaIndonesia
PhilippinesPhilippines
AustraliaAustralia
New ZealandNew Zealand

Pan-India Presence. Local Expertise.

Raipur
Bilaspur
Panaji
Vasco da Gama
Gandhinagar
Ahmedabad
Surat
Chandigarh
Gurgaon
Shimla
Manali
Bengaluru
Mysore
Kochi
Pune
Mumbai
Thane
Navi Mumbai
Hyderabad
Chennai
Coimbatore
Kolkata
Lucknow
Jaipur
Udaipur
Jodhpur
Dehradun
Haridwar
Bhubaneswar

Product Gallery

Frequently Asked Questions (FAQ)

  • Short wave infrared heaters operate at higher temperatures (up to 2600°C filament temperature) and produce shorter wavelength radiation that heats surfaces almost instantaneously, while medium wave heaters operate at lower temperatures with slower heat-up times but may be better suited for certain materials that absorb medium wave radiation more efficiently.
