Laboratory Ovens Air drafts are used in the regular heating, drying and moisture removal of the samples used in the laboratories. Kerone is one of the leading suppliers of standard and customized laboratory Ovens to meet the specialized needs of scientists, individual, Research Laboratories, Defence Installation, Educational Institute and R&D Laboratories of leading national and multinational companies for specialized research application.
Laboratory Ovens Air drafts are designed as a three walled heating units. The outer body is constructed of thick PCRC sheets which are pre-treated with primer, rust proofing and painted with lasting stove enamel or elegant powder coating. SS 304 grade stainless steel of heavy gauge makes the inner chamber. The gap in the wall is filled with high grade mineral glass wool for maximum thermal efficiency in the Laboratory Ovens Air drafts. The unit is fixed upon a robust steel frame. The castor wheel attached to the frame (for large models only) allows for easy movement of the unit inside the laboratory. It is provided with one to three stainless steel shelves as per the inner size.
Heating:
Air heaters made of Kanthal A-1 wires of suitable wattage is used to provide indirect heating from three sides. The warm air is evenly distributed within the chamber via forced air draft from bottom to top.
Temperature Range:
The temperature of the standard Laboratory Ovens ranges from 50°C above norm0al to 250°C. However, the capacity of the standard model can be modified to suit the specialized requirement of the individual customers.
Temperature Sensitivity:
The temperature inside the unit is controlled with the sensitivity of ± 1°C or much better.
Front Panel :
Front Panel of the unit consists of on/off switch, heating and mains indicator lamps, thermostat or temperature controller.
Temperature Control :
Hydraulic type German thermostat (sensitivity ± 1°C) or Microprocessor is used to maintain the temperature inside the incubator based on temperature controller and indicators.
Inner Chamber (W*D*H) Volume litres:
|
| 30*30*30 cms |
27 ltrs |
| 35*35*35 cms |
45 ltrs |
| 45*45*45 cms |
95 ltrs |
| 45*45*60 cms |
125 ltrs |
| 60*60*60 cms |
224 ltrs |
| 60*45*90 cms |
252 ltrs |
| 60*60*90 cms |
336 ltrs |
|
|
|
| |
|
| |
|
